INDCO Tri-Clamp® Mixers Are Ideal for Mixing Dairy Products

Tri-Clamp® Mount Mixers from INDCO produce ample shear to form emulsions when mixing lipophilic compounds like those often found in dairy processing applications.  Designed for sealed applications, the sanitary tri-clamp® design provides quick and easy, no-tools access to the vessel.  The Model TCM-3-100V electric variable speed unit plugs directly into a standard 120-volt outlet, providing out-of-the-box productivity.  Standard features include a 3-inch diameter tri-clamp® flange, internally mounted mechanical seal rated full vacuum to 125 psi, and a shaft coupler.  A 1 HP epoxy coated washdown motor is driven by a NEMA 4X control and provides output speed from 35-1750 rpm to put dairy products in emulsion.  The 5/8” diameter by 35” long shaft attaches to the coupler and two 5-inch, 3-blade square pitch propellers with set screws.  All wetted parts are 316 stainless steel, with optional electropolished wetted parts available. Model TCM-3-100V Tri-Clamp® Mount Mixers are ideal for many dairy mixing applications, as well as other applications within the food, pharmaceutical, and cosmetic industries.

In addition to mixers, INDCO provides a full range of mixing tanks for use within the dairy industry.  Stainless steel tanks in stationary or portable configurations are available with capacities from 15- to 1500-gallons.  Sanitary finish options available include 120-grit, #4 finish with all interior welds ground flush and polished.  Exterior welds ground and buffed smooth.  All welds passivated and leak tested.  Standard material is 304 stainless, with 316 optional.

INDCO offers sealed tank mixers from ½ to 1 ½ HP with either air or TEFC electric motors.  Tri-clamps® offered in 2-inch, 3-inch, and 4-inch sizes.  Additional information on the TCM-3-100V mixer is available at https://www.indco.com/shop/product/tcm-3-100v/3-tri-clamp-mount-1-hp-electric-washdown-direct-drive-variable-speed-mixer .

All INDCO products are made in the USA with industry leading warranties.  Their team of mixing engineers are available to provide selection and application assistance.

Located in New Albany, Indiana, INDCO is a leading manufacturer of industrial mixers.  Since 1975 they have designed and manufactured a completed lineup of mixers for batch sizes up to 50,000 gallons.  They use premium brand components in their robust designs to deliver high quality mixers that earn their customer’s trust.  In addition to premier equipment, INDCO prides itself on providing fast, friendly customer service and immediate technical support.  Full information is available on their comprehensive website, www.INDCO.com, by calling (800) 851-1049, or via email at info@INDCO.com.
